Solar Power - Home Kit/Setup - 2.4kW Inverter - DIY - Richards Bay

ARE YOU TRYING TO EXPERIENCE LOAD SHEDDING WITH THE LIGHTS STILL ON?
WELL HERE IS A DEAL YOU CANNOT MISS!
This DIY Solar Kit will not only give you a great return on your investment but will also save you a whole lot on your electricity bill, month on month.
Here is what you get:
•Synapse 2.4kW Inverter
•2 x Canadian Solar 415W Super High-Power Poly Solar Panels
•2 x Vision 100Ah 12V Deep Cycle Gel Battery (AGM) (Upgradeable on request)
•Complete Roof Mounting Kit (Aluminium Easy Install Rails, Roof Hooks, Mid clamps, End clamps)
•DC Solar Cable 10m Red & 10m Black (Additional lengths available on request)
•MC4 Connectors
•DC Battery Cabling and End Lugs
•20Amp DC Fuse
•DC Fuse Holder

Synapse 3KW 24VDC, 1000W MPPT
Which comes equipped with a unique operating system and a built-in MPPT for solar applications. In addition, there is an optional AC input that will allow a battery bank to be charged by a grid or generator connection.
Technical Specifications:
•Rated Power:2400W
•Voltage:230V AC
•Surge Power:6000VA
•Efficiency:90-93%
•Max PV Array Power:1000W
•Dimensions(mm):88d x 225w x 320h
•Max PV Array Power: 1000W
•Operating temp:-10°C to 55°C

Canadian Solar 415W Super High Power Poly PERC HiKU with MC4
HiKu is the first poly module exceeding 400 W and thus reaches one of the highest poly module power outputs in the solar industry. Combining the best technology and design, it also reduces LCOE and installation costs
Technical Specifications:
•24% more power than conventional modules
•Rating: 415W
•Efficiency: 18.8%
•Width: 1,048mm
•Height: 2,108mm
•MC4 connectors cable termination

Vision 100Ah 12V Deep Cycle Gel Battery (AGM)
•Advanced pure lead technology.
•Longer float & cycle life.
•Stronger discharge performance.
•Maintenance-free operation.
•Fully Sealed Battery
•Higher Operating Temp’s – overcharge friendly
•Special valves allow the gases to escape thus avoiding excessive pressure build-up.
•2 Year Warranty

Please visit solarsmart.africa or WhatsApps us on 0810435734 for more information and other fantastic products, equipment and specials
